Your whole job, in one report.

FoundationDraw™ brings your drawing, observations, photo and crack markups, and FoundationScan® elevation data together into one observation report like no other.

Book a Demo NowWatch the interactive demo
1

Built on Benchmark® data

FoundationScan® started with elevation data for monitoring walls and floors through Vertical, Topo and Wall Profile Benchmark® reports.

2

We listened

Contractors asked for an easy way to draw, mark up photos and map cracks so they could see the whole picture. So we built it.

3

Smart objects, not dumb widgets

Piers, cracks and markups know what they are. You set them up before you reach the job so the visit runs smoother and faster, and the software works the way your company runs.

See FoundationDraw™ in action

Click through the interactive demo, right here.

LiDAR floor outlinesPiers & symbols3D heat mapsCRM-ready exportsBenchmark® reports

Everything a foundation drawing needs

Outline the house, mark up the repair, map the elevations, and hand your customer a Project they understand at a glance.

LiDAR floor outlines

Scan interior and exterior outlines with a LiDAR-equipped iPhone Pro, walk the exterior, or start a freehand sketch that auto-straightens and stays to scale.

Piers & symbols

Piers, cracks, waterproofing, areas, fixtures and landscape from a company-wide symbol library, so every crew draws it the same way.

3D elevation heat maps

Record elevation readings on the drawing and see the whole floor in 3D. Homeowners see the problem instantly.

CRM-ready, multi-format export

Branded PDF Projects with your logo and cover photo, DXF for CAD, and CRM-ready files you can import into your office systems.

Benchmark® reports

Turn your elevation survey into a clean Benchmark® report to include with the Project.

Crew checklists

Required after photos and install logs, with numbered photo markers. The job turns green when it's done.
